TOP 2140-20T2-05
Indexable drills with unique square inserts & coolant holes, drilling depth 2xD
| Cutting Diameter (DC) | 14 mm | Overall Length (OAL) | 96 mm |
| Usable Length (LU) | 28 mm | Connection Thread Size (Ts) | M13X1.0 |
| Application | | Drilling | Tools for Swiss Machines | | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 20 mm | Length Group | 2xD |
| Shank Length (LS) | 50 mm | Body Material | Steel |
| Functional Length (LF) | 46 mm | Unit | M |
Product Features
| Family Description | Indexable drills with unique square inserts & coolant holes, drilling depth 2xD | COO | S.KOREA |
Shipping Info
Weight per item
0.1900
