| Cutting Width (CW) | 13 mm | Application | | Ext. Grooving | Int. Grooving | Int. Grooving (side limit) | |
| Insert Thickness (S) | 5.35 mm | Applicable Material | | Stainless Steel | Cast Iron | Hard Materials | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | |
| Inscribed Circle Diameter (IC) | 12.7 mm | Measurement Type | Metric |
| Fixing Hole Diameter (D1) | 5.5 mm | Tool Type | Groove-Turn Utility Inserts |
| Coating | Uncoated | Body Material | Carbide |
| Grade | IC20 | Unit | M |
| Cutting Edge Material | Carbide |
Product Features
| Family Description | Blank inserts for wide profile grooving. | FamilyName | XNUW |
| COO | Israel | BrandName | Iscar |
Shipping Info
Weight per item
0.0181
Name
Groove/Turn Indexable Inserts
FamilyName
XNUW
BrandName
Iscar
